Gauge valves
Developed for high pressures and sudden temperature changes, Boscarol gauge valves are ideal for regulating or interrupting the flow of supply or exhaust fluids, thus supporting pressure gauges. They are manufactured with high quality materials which are selected, treated and processed according to each specific condition of use.
Technical features
Available in three tuned up solutions: OT/58, AISI/316, ASTM A 105
Operating parts in zinc-coated ASTM A 105 steel can be provided for the AISI/316 series
Double version with 2 or 3 ways
3-way version with diameter 40 flange for the connection of the control pressure gauge
2-way manifold
Double gauge valve to reduce operating costs on measuring systems and spare double valves with different nipples and fittings.
| Passage mm (inch) | Ø 3 mm | |
|---|---|---|
| Operating limit | PTFE | 200 bar - 100°C |
| GRAPHITE | 120 bar - 350°C | |
| Couplings |
Threaded female inlet/outlet: 1/2 NPT Female threaded bleeding hole: 1/4 |
|
| Certification | Directive 94/9/UE (ATEX) | |
| Materials | Body and stem | Stainless steel 316 |
| Pin shutter | Stainless steel 316 - with stellite insert | |
| Seal | PTFE or GRAPHITE | |
| Handwheel | Stainless steel 304 | |
3-way manifold
In systems including a shunt route in a distribution circuit, it momentarily allows not to reduce the potential of the system, thus excluding performance drops.
| Passage mm (inch) | Ø 3 mm | |
|---|---|---|
| Operating limit | PTFE | 200 bar - 100°C |
| GRAPHITE | 120 bar - 400°C | |
| Couplings | Threaded male/female (NPT, BSP) 1) | |
| Certification | Directive 94/9/UE (ATEX) | |
| Materials | Body and stem | Stainless steel 316 |
| Pin shutter | Stainless steel 316 - with stellite insert | |
| Seal | PTFE or GRAPHITE | |
| Handwheel | Stainless steel 304 | |
Valves
All the quality of Boscarol technological solutions available in a wide range catered to every single need.
|
Series |
Brass 2/3 way | Carbon steel 2/3 vie | Stainless steel 2/3 vie | |
|---|---|---|---|---|
|
Passage |
Ø 3 mm 1) | |||
| Operating limit |
PTFE |
125 bar - 100°C |
250 bar - 100°C |
400 bar - 100°C |
| GRAFITE |
125 bar - 200°C |
120 bar - 300°C |
120 bar - 400°C |
|
|
Couplings |
Threaded male/female (NPT, BSP, BSPT, API)2) | |||
|
Reference standards D |
DIN 16270 - 16271 |
|||
|
Certification |
Directive 94/9/UE (ATEX) |
|||
|
Materials |
Body |
Brass CW617N 3) |
Carbon steel A105 4) |
Stainless steel AISI 316 |
|
Stem |
Stainless steel 410 |
Stainless steel 410 |
Stainless steel AISI 316 |
|
|
Pin shutter |
Hardened stainless steel 420 |
Hardened stainless steel 420 |
Stainless steel 316 with stellite insert |
|
|
Seal |
PTFE or GRAPHITE |
|||
1) Anche Ø 4,5 mm
2) Altri tipi di filettatura a richiesta
3) Sbiancato a richiesta
4) Zincato o brunito
